LED High Bay Housing MLT-HBH-CS-II
LED High Bay Housing MLT-HBH-CS-II
Brief Introduction
This LED high bay housing fixture MLT-HBH-CS-II is the small size of round SMD LED high bay housing fixture from Moonlight LED high bay C series. Modern design, precision die-casting molded and superior corrosion resistant coating finish housing, make this housing can be used for variety of LED commercial and industry lighting applications.
Feature
- Durable aluminum alloy die-casting housing for heavy-duty lighting applications.
- Casting-integral heat sink with fins increased air flow velocity providing maximum passive thermal management.
- Easy drainage fins system.
- Multiple brand power supplies compatibility.
- Plastic electrostatic spraying to resist corrosion, chipping and fading.
- High light transmittance tempered glass or PC Lens.
- Silicon gaskets.
- SUS304 stainless steel bolts and hook for fastening
- IP65 rated, protect from all dust and harsh weather.
- Standard black finish.
- Multiple mounting solution for different installation applications.
- Safety rope is provided for security.
- Easy to assemble, install and linemen friendly maintain.
Mechanical Dimensions
Parameter
| Model No. | LED High Bay Housing MLT-HBH-CS-II |
| Dimension of Housing | 35.8cm(φ)*13cm(H) |
| Fixture Material | Die-casting Aluminum Alloy |
| Diffuser Material | High Transmittance Tempered glass/PC |
| Surface Finish Color | Black or Customized color |
| Effective MCPCB Mounting Size | 236.8mm(Φ) |
| Recommended LED Power | 80W to 150W |
| Driver Compatibility | Multiple Brand |
| Beam Angle | 40°/80°/120° |
| Mounting Method | Hook /Pendant /Bracket Mounting Options |
Type of Mounting
Pictures
Packing Information
| Net Weight | kg/PCS |
| Gross weight | kg/carton |
| Quantity | PCS/ carton |
| Carton Size | cm(L)*cm(W)*cm(H) |
Application
This heavy-duty, modern design, energy-efficient and cost-effective LED high bay housing fixture is typically used as 80W-150W LED high bay light. LED high bay lights are specifically designed for taller ceilings and larger areas. They focus light more directly to create powerful illumination at a long range. This makes them perfect for commercial and industrial applications such as supermarkets, exhibition halls, big-box retail stores, sporting venues, manufacturing plants, warehouses, recreation centers, hangars and storage facilities. These LED industry lighting fixtures improve visibility and worker safety while enhancing productivity.
