LED High Bay Housing MLT-HBH-CS-I
LED High Bay Housing MLT-HBH-CS-I
Brief Introduction
This LED highbay housing fixture MLT-HBH-CS-I is the small size of COB LED high bay housing fixture with chimney reflector from Moonlight LED high bay C series. In this LED warehouse lighting family, there are other four models, MLT-HBH-CXL-I, MLT-HBH-CL-I, MLT-HBH-CM-I and MLT-HBH-CXS-I. Modern design, high efficacy heat pipe as the core and superior Nano coating finish heatsink make this housing can be used for variety of LED commercial and industry lighting applications.
Feature
- Phase transition heat pipe in the center of the heatsink for heavy-duty and high efficiency thermal management.
- Nano-coating appearance enhances heat dissipation and resist corrosion, chipping and fading.
- Extruded aluminum fins at the outside of the heatsink increased air flow velocity providing maximum passive thermal management.
- Meanwell HLG series or similar power supplies compatibility.
- High light transmittance glass lens for different beam angles.
- Silicon gaskets.
- Stainless steel bolts for fastening
- IP65 rated, protect from all dust and harsh weather.
- Standard black finish.
- Safety rope is provided for security.
- Easy to assemble, install and linemen friendly maintain.
Mechanical Dimensions
Parameter
| Model No. | LED Highbay Housing MLT-HBH-CS-I |
| Dimension of Housing | 50cm(Φ)* 32.7cm(H) |
| Fixture Material | Copper + Aluminum + PC |
| Diffuser Material | High Transmittance Tempered Glass |
| Reflector Material | Aluminum/PC(60° only) |
| Surface Finish Color | Black or Customized color |
| Recommended LED Power | 60W to 70W |
| Driver Compatibility | Meanwell HLG Series or Similar |
| Angle of Glass Lens | 60°/90°/120° |
| Angle of Chimney | 120° |
| Mounting Method | Hook |
Pictures
Packing Information
| Net Weight | kg/PCS |
| Gross weight | kg/carton |
| Quantity | PCS/ carton |
| Carton Size | cm(L)* cm(W)* cm(H) |
Application
This heavy-duty, modern design, energy-efficient and cost-effective LED highbay housing fixture is typically used as 60W-70W LED high bay light for warehouse lighting. LED high bay lights are specifically designed for taller ceilings and larger areas. They focus light more directly to create powerful illumination at a long range. This makes them perfect for commercial and industrial applications such as supermarkets, exhibition halls, big-box retail stores, sporting venues, manufacturing plants, warehouses, recreation centers, hangars and storage facilities. These LED industry lighting fixtures improve visibility and worker safety while enhancing productivity.
