LED Street Light Housing MLT-SLH-BM-II
LED Street Light Housing MLT-SLH-BM-II
Brief Introduction
This LED street lamp housing MLT-SLH-BM-II is the medium size of SMD LED street light housing fixture from Moonlight LED street light B series. In this light housing family, there are other two models, MLT-SLH-BS-II and MLT-SLH-BL-II. Modern design, precision die-casting molded and superior corrosion resistant coating finish housing with standard NEMA twist lock photocell mounting platform, make this housing can be used for variety of LED roadway lighting applications.
Data Sheet
Feature
- Durable aluminum alloy die-casting LED street lamp housing for heavy-duty outdoor lighting applications.
- Casting-integral heat sink with fins increased air flow velocity providing maximum passive thermal management.
- Easy drainage fins system.
- Separate LED light engine and driver box for easy maintenance.
- Tool-less design for replace the LED driver without any tool.
- Large driver box complies with Meanwelll HVG series drivers.
- Both cover and bottom of the driver box have the GND bosses for security.
- Plastic electrostatic spraying to resist corrosion, chipping and fading.
- Adjustable knuckle slip fitter with SUS304 stainless steel hardware secures fixture to pole arm.
- 5mm high light transmittance tempered glass diffuser.
- Silicon gaskets.
- SUS304 stainless steel bolts and clips for fastening
- Standard S6000 socket and NEMA twist lock photocell mounting platform for lighting control.
- IP66 rated, protect from all dust and harsh weather.
- Standard Gray finish.
- Easy to assemble, install and linemen friendly maintain.
Mechanical Dimensions
Parameter
| Model No. | LED Street Lamp Housing MLT-SLH-BM-II |
| Dimension of Housing | 77cm(L)*30.1cm(W)*9.3cm(H) |
| Fixture Material | Die-casting Aluminum Alloy |
| Surface Finish Color | Gray or Customized color |
| Material of Diffuser | High Transmittance Tempered glass |
| Effective MCPCB Mounting Size | 410mm(L)*285mm(W) |
| Recommended LED Power | 120W to 180W |
| Driver Box Dimension | 267mm(L)*112mm(W)*87mm(H) |
| Pole Mounting | Accommodates up to Φ65mm pipe |
| Adjustable Slip Fitter | -90°to +90° |
| Standard Photocell | Optional |
| IP Rating | IP66 |
Pictures
Packing Information
| Net Weight | 7.30kg/PCS |
| Gross weight | 8.20kg/carton |
| Quantity | 1PCS/ carton |
| Carton Size | 82cm(L)*35cm(W)*14cm(H) |
Application
This heavy-duty, modern design and cost-effective LED street lamp housing fixture is typically used as 120W-180W LED street lighting fixture. LED street lighting is used extensively in urban settings, along small town downtown main streets, in residential neighborhoods, in commercial districts, public squares, in industrial parks, at interstate highway interchanges, bridges, and rural intersections.
