LED Street Light Housing MLT-SLH-AS-I
LED Street Light Housing MLT-SLH-AS-I
Brief Introduction
This LED street light housing fixture MLT-SLH-AS-I is the smallest size of COB LED street light housing fixture from Moonlight LED street lighting fixture A series. Modern design, precision die-casting molded and superior corrosion resistant coating finish housing with standard NEMA twist lock photocell mounting platform, make this housing can be used for variety of LED roadway lighting applications.
Feature
- Durable aluminum alloy die-casting housing for heavy-duty outdoor lighting applications.
- Casting-integral heat sink with fins increased air flow velocity providing maximum passive thermal management.
- Easy drainage fins system.
- Plastic electrostatic spraying to resist corrosion, chipping and fading.
- Rugged heavy gauge, 4 bolt, galvanized clamp with stainless steel hardware secures fixture to pole arm.
- 5mm high light transmittance tempered glass diffuser.
- Silicon gaskets.
- Stainless steel bolts for fastening
- Standard NEMA Twist lock photocell mounting platform for lighting control.
- IP65 rated, protect from all dust and harsh weather.
- Standard Gray finish.
- Easy to assemble, install and maintain.
Mechanical Dimensions
Parameter
| Model No. | LED Street Light Housing MLT-SLH-AS-I |
| Dimension of Housing | 35.3cm(L)*13cm(W)*6cm(H) |
| Fixture Material | Die-casting Aluminum Alloy |
| Surface Finish Color | Gray or Customized color |
| Material of Diffuser | High Transmittance Tempered glass |
| Recommended LED Power | 20W to 50W |
| Driver Box Dimension | 87mm(L)*68mm(W)*43mm(H) |
| Pole Mounting | Accommodates Φ40mm pipe |
| Adjustable Slip Fitter | Not available |
| Photocell | Optional |
| IP Rating | IP65 |
Pictures
Packing Information
| Net Weight | 1.50kg/PCS |
| Gross weight | 6.5kg/Carton |
| Quantity | 4PCS/ carton |
| Carton Size | 40cm(L)*33.5cm(W)*19.5cm(H) |
Application
This unique, heavy-duty, modern design and cost-effective LED street light housing fixture is typically used as 20W-50W COB LED street lighting fixture. LED street lighting is used extensively in urban settings, along small town downtown main streets, in residential neighborhoods, in commercial districts, public squares, in industrial parks, at interstate highway interchanges, bridges, and rural intersections. This small LED street light housing fixture is typically used as solar powered LED street lighting applications.
