LED Street Light Housing MLT-SLH-CS-II
LED Street Light Housing MLT-SLH-CS-II
Brief Introduction
This LED street light housing fixture MLT-SLH-CS-II is the smallest size of SMD LED street light housing fixture from Moonlight LED street light C series. Modern design, precision die-casting molded and superior corrosion resistant coating finish housing, make this housing can be used for variety of LED roadway lighting applications.
Feature
- Durable aluminum alloy die-casting housing for heavy-duty outdoor lighting applications.
- Casting-integral heat sink with fins increased air flow velocity providing maximum passive thermal management.
- Plastic electrostatic spraying to resist corrosion, chipping and fading.
- Rugged heavy gauge, 4 bolt, galvanized clamp with stainless steel hardware secures fixture to pole arm.
- 5mm high light transmittance tempered glass diffuser.
- Silicon gaskets.
- Stainless steel bolts for fastening
- IP65 rated, protect from all dust and harsh weather.
Mechanical Dimensions
Parameter
| Model No. | LED Street Light Housing MLT-SLH-CS-II |
| Dimension of Housing | 40cm(L)*21cm(W)*6cm(H) |
| Fixture Material | Die-casting Aluminum Alloy |
| Surface Finish Color | Gray or Customized color |
| Material of Diffuser | High Transmittance Tempered glass |
| Effective MCPCB Mounting Size | 392mm(L)*203mm(W) |
| Recommended LED Power | 30W to 60W |
| Driver Box Dimension | 180mm(L)*120mm(W)*30mm(H) |
| Pole Mounting | Accommodates up to Φ65mm pipe |
| Adjustable Slip Fitter | Not Available |
| Standard Photocell | Not Available |
| IP Rating | IP65 |
Pictures
Packing Information
| Net Weight | 2.60kg/PCS |
| Gross weight | 5.71kg/carton |
| Quantity | 2PCS/ carton |
| Carton Size | 54.5cm(L)*27.5cm(W)*19cm(H) |
Application
This heavy-duty, modern design and cost-effective LED street light housing fixture is typically used as 30W-80W LED street lighting fixture. LED street lighting is used extensively in urban settings, along small town downtown main streets, in residential neighborhoods, in commercial districts, public squares, in industrial parks, at interstate highway interchanges, bridges, and rural intersections. This flat LED street light housing is mainly used as solar powered LED street lighting fixture for places of lack of power, such as island, remote countryside, etc.
