LED Street Light Housing MLT-SLH-IS-II
LED Street Light Housing MLT-SLH-IS-II
Brief Introduction
This LED module street light housing fixture MLT-SLH-IS-II is the small size of LED module street light housing fixture from Moonlight LED street light I series. Modern uniformed LED modules design, precision die-casting molded and superior corrosion resistant coating finish frame with extruded aluminum module as LED lighting engine, make this housing can be used for variety of LED roadway lighting applications.
Feature
- Durable aluminum alloy die-casting frame with extruded LED modules for heavy-duty outdoor lighting applications.
- Individual and easy maintenance LED street light module.
- Plastic electrostatic spraying to resist corrosion, chipping and fading.
- 4 bolts with steel hardware secures fixture to pole arm.
- High light transmittance PC lenses as diffuser.
- Silicon gaskets.
- Steel bolts for fastening
- IP65 rated, protect from all dust and harsh weather.
- Standard Gray finish.
- Easy to assemble, install and maintain.
Mechanical Dimensions
Parameter
| Model No. | LED Street Light Housing MLT-SLH-IS-II |
| Dimension of Housing | 64.5cm(L)*32.6cm(W)*8.5cm(H) |
| Fixture Material | Die-casting and Extruded Aluminum Alloy |
| Surface Finish Color | Gray or Customized color |
| Material of Diffuser | High Transmittance PC lenses |
| LED Module Size | (275-300)mm(L)* 70cm(W) |
| Compatibility LEDs | Lumileds 3030 or similar |
| Lens size | 236mm(L)*70mm(W) |
| Lenses Degree | 70° × 140° |
| Recommended LED Power | 80W to 100W |
| Driver Box Dimension | 250mm(L)*93mm(W)*70mm(H) |
| Pole Mounting | Accommodates up to Φ65mm pipe |
| Adjustable Slip Fitter | Not Available |
| Standard Photocell | Not Available |
| IP Rating | IP65 |
Pictures
Packing Information
| Net Weight | 5.72kg/PCS |
| Gross weight | 12.04kg/carton |
| Quantity | 2PCS/ carton |
| Carton Size | 66cm(L)*34cm(W)*19.5cm(H) |
Application
This heavy-duty, modern design and cost-effective LED street light housing fixture is typically used as 80W-100W LED module street lighting fixture. LED street lighting is used extensively in urban settings, along small town downtown main streets, in residential neighborhoods, in commercial districts, public squares, in industrial parks, at interstate highway interchanges, bridges, and rural intersections.
