Street Lamp Body MLT-SLH-ML-II
MLT-SLH-ML-II street lamp body featuring robust die-cast aluminum housing, designed for reliable outdoor LED lighting.
Brief Introduction
The MLT-SLH-ML-II is a large-format street lamp body in Moonlight’s M Series
(MLT-SLH-MS-II, MLT-SLH-MM-II & MLT-SLH-ML-II)
of SMD LED housings, engineered for high-wattage LED street lighting applications. Designed with a modern, streamlined appearance, this street lamp body fixture is precision die-cast from durable aluminum and finished with a high-grade, corrosion-resistant coating to withstand harsh outdoor environments.
Built for flexibility, the street lamp body MLT-SLH-ML-II features a standard twist-lock photocell mounting platform and a spacious internal layout, making it compatible with a wide range of smart lighting components. Its robust construction and versatile design make it an ideal choice for highways, industrial zones, city streets, and other large-scale roadway lighting projects requiring both performance and reliability.
Feature
Reinforced Aluminum Street Lamp Body: Crafted from high-quality die-cast aluminum alloy, the MLT-SLH-ML-II street lamp body is built for long-lasting performance in high-demand, large-scale outdoor lighting applications.
Minimalist, Finless Exterior: Its ribbon-free, aerodynamic design offers a contemporary appearance while reducing dirt accumulation and wind drag—perfect for modern urban landscapes.
Engineered Thermal Control: The LED street light housing is designed with structural optimization based on FEA simulations, ensuring reliable thermal dissipation and maintaining LED performance over time.
Modular for Maintenance Efficiency: A separate driver box and LED chamber layout allows for quick, tool-free driver replacement, reducing service time and minimizing downtime in the field.
Integrated Grounding Solution: GND mounting points are pre-installed at the bottom of the driver compartment to ensure stable and compliant grounding during installation.
Protective Coating for Longevity: A durable plastic electrostatic powder coating guards against corrosion, UV fading, and surface wear, even in coastal or industrial environments.
Heavy-Duty Mounting System: Equipped with an adjustable knuckle slip fitter and SUS304 stainless steel components, the housing ensures solid and secure pole arm installation in various orientations.
Dual Mounting Compatibility: Supports both side-entry and post-top mounting, allowing flexible deployment across different roadway and area lighting scenarios.
Impact-Resistant Optical Lens: A 4mm high-transmission tempered glass diffuser delivers uniform light output and provides excellent resistance to impact and harsh environmental factors.
Weather-Sealed Build: Silicone gaskets and stainless-steel bolts ensure the fixture remains sealed and protected against dust, water ingress, and vibration over long-term operation.
Supports High-Wattage LED Drivers: Specifically compatible with Mean Well XLG-200 series LED drivers, providing robust, energy-efficient power for high-output LED street lighting.
Photocell-Ready for Smart Lighting: Comes pre-equipped with a standard twist-lock S6000 socket, enabling integration with photocells or smart control systems for automated lighting functions.
Quick Power Isolation for Safety: Includes an internal quick-disconnect terminal block, allowing safe and efficient power cut-off during driver servicing or inspection.
IP65-Rated Environmental Protection: Rated IP65, this large-format LED street lamp body is fully sealed against dust and water jets, ensuring reliable operation in all weather conditions.
Professional Appearance: Finished in a clean, neutral gray tone, this street lamp body blends well with both urban and industrial settings, maintaining a consistent and professional look.
Installer-Friendly Design: Engineered with ease of use in mind, this fixture is optimized for fast assembly, hassle-free installation, and reduced maintenance effort in high-access areas.
Street Lamp Body MLT-SLH-ML-II Mechanical Dimensions
Parameter
| Model No. | Street Lamp Body MLT-SLH-ML-II |
| Dimension of Housing | 70.5cm(L)*34.5cm(W)*11.2cm(H) |
| Fixture Material | Die-casting Aluminum Alloy |
| Die-casting Aluminum Alloy Weight | 4500g |
| Surface Finish Color | Gray or Customized color |
| Material of Diffuser | 4mm High Transmittance Tempered glass |
| Effective MCPCB Mounting Size | 200mm(L)*200mm(W) |
| Compatible Lenses | 16PCS 50mm*50mm Lenses |
| Recommended LED Power | 150W to 200W |
| Driver Box Dimension | 230mm(L)*155mm(W)*60mm(H) |
| Pole Mounting | Accommodates up to Φ60mm pipe |
| Adjustable Slip Fitter | -15°to +15° |
| Standard Photocell | Optional |
| Quick Disconnection Terminal Block | Optional |
| IP Rating | IP65 |
Street Lamp Body MLT-SLH-ML-II Pictures
Packing Information
| Net Weight | 5.72kg/PCS |
| Gross weight | 6.68kg/carton |
| Quantity | 1PCS/ carton |
| Carton Size | 76cm(L)*35cm(W)*15cm(H) |
Application
The MLT-SLH-ML-II LED aluminum street light body is designed for 150W–200W fixtures, offering a powerful and reliable solution for high-output street lighting applications.
Perfect for urban roads, residential streets, industrial zones, commercial areas, bridges, and highway interchanges, it delivers long-lasting performance in both city and rural settings.
Video Show
This L Size LED street lamp body MLT-SLH-ML-II is ideal for larger LED street light installations. For smaller or medium options, see our S size LED street light housing MLT-SLH-MS-II and M size LED street light housing MLT-SLH-MM-II housings.
