Street Lamp Housing MLT-SLH-MS-II
MLT-SLH-MS-II street lamp housing – robust die-cast aluminum design for long-lasting outdoor lighting.
Brief Introduction
The MLT-SLH-MS-II is a compact street lamp housing from Moonlight’s M Series(MLT-SLH-MS-II, MLT-SLH-MM-II & MLT-SLH-ML-II), designed for SMD LED applications. With a sleek, finless exterior and modern profile, this housing is precision die-cast and finished with a high-performance, corrosion-resistant coating to ensure long-lasting durability in demanding outdoor environments.
This street lamp housing features a separated structure for the LED module and power compartment, which enhances thermal performance and simplifies maintenance. The spacious power chamber is designed not only to accommodate the LED driver but also to house a surge protection device (SPD) and a quick disconnector for improved electrical safety.
A tool-less quick-release latch allows for easy access to the power compartment, and once opened, the integrated breaker enables fast and secure power disconnection, making on-site servicing more efficient.
Engineered with a standard twist-lock photocell mounting platform, this street lamp housing is ideal for a wide range of LED roadway and urban lighting applications, delivering both performance and convenience in a compact form.
Feature
Rugged Build Quality: Crafted from high-strength die-cast aluminum alloy, this street lamp housing is built to endure the toughest outdoor environments and demanding roadway lighting applications.
Streamlined Aesthetic: A clean, finless and compact form factor delivers a modern appearance while minimizing wind resistance and visual clutter.
Superior Heat Dissipation: Engineered using advanced FEA thermal modeling, the internal layout optimizes airflow and component spacing for effective thermal control without external fins.
Maintenance-Friendly Design: Featuring a modular, compartmentalized layout, the LED light engine and driver chamber are isolated—allowing for tool-free driver access and swift replacement in the field.
Grounding Protection: Equipped with dedicated GND bosses at the base of the power compartment, ensuring secure electrical grounding and enhanced safety compliance.
Corrosion-Resistant Surface: The housing is coated with a durable plastic electrostatic spray finish, delivering strong resistance to corrosion, flaking, and UV-induced fading.
Flexible Pole Mounting: Comes with an adjustable knuckle slip fitter and SUS304 stainless steel hardware for secure and stable pole attachment in various outdoor setups.
Multi-Angle Installation Options: Supports both side-entry and post-top configurations, with interchangeable mounting components that allow for precise on-site positioning.
Premium Optical System: Features a 4mm high-transmittance tempered glass lens, ensuring even light diffusion and minimal loss for efficient illumination.
Reliable Sealing Components: Uses silicone gaskets and SUS304-grade stainless steel bolts and clips to guarantee long-term sealing integrity and fixture stability.
Trusted LED Driver Compatibility: Fully compatible with the Mean Well XLG-75 series LED driver, ensuring consistent performance and global brand reliability.
Integrated Smart Control: Includes a standard twist-lock photocell base (S6000 socket) to enable smart lighting control, automatic on/off operation, and compatibility with most photocells.
Safe Power Disconnection: Designed with a quick-disconnect terminal block, allowing service personnel to isolate the driver power safely and efficiently during maintenance.
Weatherproof Performance: Rated IP65, the housing provides complete protection against dust ingress and heavy rain, making it suitable for all weather conditions.
Professional Exterior Finish: Standard industrial gray coating offers a neutral and refined finish that blends seamlessly into urban and industrial landscapes.
User-Oriented Design: From installation to upkeep, the fixture supports fast assembly and lineman-friendly maintenance, reducing labor time and improving efficiency on site.
Street Lamp Housing MLT-SLH-MS-II Mechanical Dimensions
Parameter
| Model No. | Street Lamp Housing MLT-SLH-MS-II |
| Dimension of Housing | 56.1cm(L)*24.6cm(W)*10.7cm(H) |
| Fixture Material | Die-casting Aluminum Alloy |
| Die-casting Aluminum Alloy Weight | 2500g |
| Surface Finish Color | Gray or Customized color |
| Material of Diffuser | 4mm High Transmittance Tempered glass |
| Effective MCPCB Mounting Size | 150mm(L)*100mm(W) |
| Compatible Lenses | 6PCS 50mm*50mm Lenses |
| Recommended LED Power | 30W to 80W |
| Driver Box Dimension | 140mm(L)*80mm(W)*55mm(H) |
| Pole Mounting | Accommodates up to Φ60mm pipe |
| Adjustable Slip Fitter | -15°to +15° |
| Standard Photocell | Optional |
| Quick Disconnection Terminal Block | Optional |
| IP Rating | IP65 |
Street Lamp Housing MLT-SLH-MS-II Pictures
Packing Information
| Net Weight | 2.90kg/PCS |
| Gross weight | 3.46kg/carton |
| Quantity | 1PCS/ carton |
| Carton Size | 63cm(L)*26.5cm(W)*14.5cm(H) |
Application
This rugged, budget-friendly street lamp housing brings a clean, contemporary look to 30 W – 80 W LED roadway fixtures. Its versatile, heavy-duty design makes it the perfect fit for city boulevards, small-town main streets, residential lanes, commercial districts, public plazas, industrial parks, highway interchanges, bridge approaches, and rural crossroads—anywhere reliable LED street lighting is needed.
Video Show
This S size LED street lamp housing MLT-SLH-MS-II is suitable for compact LED street light installations. For medium or larger options, see our M size LED street light housing MLT-SLH-MM-II and L size LED street light housing MLT-SLH-ML-II.
