LED Street Light Housing MLT-SLH-EL-II
LED Street Light Housing MLT-SLH-EL-II
Brief Introduction
This street light enclosure MLT-SLH-EL-II is the large size of SMD LED street light body fixture from Moonlight LED street light E series. In this LED street light shell family, There is also a smaller model named MLT-SLH-EM-II. Modern design, precision die-casting molded and superior corrosion resistant coating finish housing with standard twist lock photocell mounting platform, make this housing can be used for variety of LED roadway lighting applications.
Data Sheet
Feature
- Durable aluminum alloy die-casting street light enclosure for heavy-duty outdoor lighting applications.
- Casting-integral heat sink with fins increased air flow velocity providing maximum passive thermal management.
- Easy drainage fins system.
- Separate LED light engine and driver box for easy maintenance.
- Tool-less design for replace the LED driver without any tool.
- Large driver box complies with Meanwelll HVG series drivers.
- Both cover and bottom of the driver box have the GND bosses for security.
- Plastic electrostatic spraying to resist corrosion, chipping and fading.
- Adjustable knuckle slip fitter with stainless steel hardware secures fixture to pole arm.
- 5mm high light transmittance tempered glass diffuser.
- Silicon gaskets.
- Stainless steel bolts and clips for fastening
- IP65 rated, protect from all dust and harsh weather.
- Standard Gray finish.
Easy to assemble, install and linemen friendly maintain.
Mechanical Dimensions
Parameter
| Model No. | Street Light Enclosure MLT-SLH-EL-II |
| Dimension of Housing | 72.3cm(L)*31.8cm(W)*6.2cm(H) |
| Fixture Material | Die-casting Aluminum Alloy |
| Surface Finish Color | Gray or Customized color |
| Material of Diffuser | High Transmittance Tempered glass |
| Effective MCPCB Mounting Size | 470mm(L)*250mm(W) |
| Recommended LED Power | 200W to 280W |
| Driver Box Dimension | 250mm(L)*150mm(W)*50mm(H) |
| Pole Mounting | Accommodates up to Φ65mm pipe |
| Adjustable Slip Fitter | 0°to +90° |
| Standard Photocell | N/A |
| IP Rating | IP65 |
Pictures
Packing Information
| Net Weight | 9.58kg/PCS |
| Gross weight | 10.80kg/carton |
| Quantity | 1PCS/ carton |
| Carton Size | 85cm(L)*37.5cm(W)*18cm(H) |
Application
This heavy-duty, modern design and cost-effective LED street light enclosure fixture is typically used as 200W-280W LED street lighting fixture. LED street lighting is used extensively in urban settings, along small town downtown main streets, in residential neighborhoods, in commercial districts, public squares, in industrial parks, at interstate highway interchanges, bridges, and rural intersections.
