LED Wall Pack Retrofit Housing MLT-WPRH-AM
LED Wall Pack Retrofit Housing MLT-WPRH-AM
Brief Introduction
This heavy-duty, cost-efective anticorrosion wall pack housing fixtur MLT-WPRH-AM for LED retrofit is the medium size wall-mounted housing which has been used as traditional 250 watt metal halides lighting fixture before, but this lighting fixture can be retrofit LED wall pack light with LEDs, heat sink and redesigned internal optical system to minimize upward light spread and get much higher efficacy and long lifespan. LED Wall pack retrofit housing can be retrofitted LED wall pack which used as LED security lighting application for many places. In this series, we also have one smaller model MLT-WPRH-AS and on bigger model MLT-WPRH-AL.
Feature
- Durable aluminum die-casting housing for heavy-duty outdoor lighting applications.
- Plastic electrostatic spraying to resist corrosion, chipping and fading.
- High light transmittance heat and shock-resistant borosilicate glass prismatic diffuser.
- Silicon foam gaskets.
- Multiple knockouts for mounting convenience.
- 1/2″ conduit openings with plugs for conduit mounting.
- IP65 rated, protect from all dust and harsh weather.
- Standard bronze finish.
- Supports Semi Cut-off Mode
- Easy to retrofit, install and maintain.
Mechanical Dimensions
Parameter
| Model No. | LED Wall Pack Retrofit Housing MLT-WPRH-AM |
| Dimension of Housing | 45.2cm(L)*25cm(W)*24cm(H) |
| Fixture Material | Die-casting Aluminum |
| Surface Finish Color | Bronze or Customized color |
| Material of Diffuser | Borosilicate Prismatic Glass |
| Mounting Type | Wall Mount |
| Equal Metal Halide Power | 250W |
| IP Rating | IP65 |
Pictures
Packing Information
| Net Weight | 4.56kg/PCS |
| Gross weight | 5.40kg/Carton |
| Quantity | 1PCS/ carton |
| Carton Size | 48.5cm(L)*27cm(W)*28cm(H) |
Application
With customized LED, mounted heatsink and optics design, or LED wall pack retrofit kits(normally include LEDs and heat sink, and sometimes we call it LED light engine.) from the market, this wall pack housing can be retrofitted LED wall pack easily. Wall pack lighting fixtures are typically applied as wall-mounted security lighting, commercial lighting that are installed on the sides of buildings, warehouses, parking garages, building walkways, pedestrian walkways, and other places around commercial buildings.
